Specifications

Stopcock Chromatography Column · Specifications

The following are general specifications. For custom sizes or special joint sizes, please contact our sales team.

ID	Length	Type	Material
10mm	200mm	Straight	Borosilicate 3.3
20mm	300mm	Straight	Borosilicate 3.3
30mm	400mm	Straight	Borosilicate 3.3
40mm	500mm	Straight	Borosilicate 3.3
50mm	500mm	Straight	Borosilicate 3.3

* Custom sizes and bulk procurement solutions available. Welcome to inquire.

Product Description

Borosilicate 3.3 · Std Joint · With PTFE Stopcock · Flow Control

Key Features

Stopcock： Refer to the actual product and specification sheet
PTFE： Refer to the actual product and specification sheet
Standard taper： Refer to the actual product and specification sheet
Flow control： Refer to the actual product and specification sheet
Corrosion resistant： Refer to the actual product and specification sheet

Quality Assurance

Every product undergoes strict dimensional inspection, joint taper testing, and thermal resistance testing to ensure compliance with GB/ISO/ASTM standard joint requirements.

Note: Ensure joints are clean and dry before use to prevent sticking. Rotate gently when connecting, do not force.

Applications

Typical Applications

Column Chromatography

Purification of natural products and synthetic compounds

Protein Purification

Affinity, ion exchange, gel filtration

Environmental Analysis

Pollutant enrichment, sample preparation

Education

Chromatography teaching labs in universities and research institutes

Tip: Chromatography columns can be used with standard joint accessories. It is recommended to use fittings of the same joint size for sealing.

Operation & Maintenance

User Guide

Preparation

Inspect column for cracks, chips, or scratches on joints
Clean joint surfaces with a soft cloth to remove particulates
If packing is needed, ensure the frit (if present) is intact

Packing & Connection

Secure the column vertically on a stand, close the stopcock (if present)
Add eluent to wet the column, slowly add packing material and tap gently to ensure even settling
Connect the upper joint to a solvent reservoir or pump, open the stopcock to start chromatography

Cleaning & Maintenance

Immediately rinse the column with appropriate solvent after use to remove residues
If the frit is blocked, use ultrasonic cleaning or back-flushing
Store with joints clean and dry, wrap with soft paper to prevent sticking

Care & Notes

Show care & notes

Safety Tips

Pay attention to pressure limits when operating high-pressure systems
Ensure good ventilation when using organic solvents

Do not

Do not use cracked or chipped columns to avoid leakage or breakage

Stopcock Chromatography Column

Specifications
