Specifications
Specifications
Standard specifications for silicone tubing. Items marked Customizable are available upon request.
Request custom specs
| ID (mm) | Wall (mm) | OD (mm) | Temp Range | Material |
|---|
| 1 | 1.5 | 4 | -60~250°C | VMQ |
| 2 | 1.5 | 5 | -60~250°C | VMQ |
| 3 | 2 | 7 | -60~250°C | VMQ |
| 4 | 2 | 8 | -60~250°C | VMQ |
| 5 | 2.5 | 10 | -60~250°C | VMQ |
| 6 | 2.5 | 11 | -60~250°C | VMQ |
| 8 | 3 | 14 | -60~250°C | VMQ |
| 10 | 3 | 16 | -60~250°C | VMQ |
| 12 | 3.5 | 19 | -60~250°C | VMQ |
| 15 | 4 | 23 | -60~250°C | VMQ |
| 20 | 4 | 28 | -60~250°C | VMQ |
Dimensions are typical values. Custom sizes are available upon request.
📌 Customization Options:
• ID customization (1~50mm)
• Wall thickness customization (1.5~8mm)
• Color options (translucent / clear / custom)
• Custom sizes upon request
Product Description
I. Overview
Silicone tubing is one of the most versatile flexible tubing products in laboratories. Manufactured from high-quality silicone rubber (VMQ), it offers excellent temperature resistance (-60~250°C), good flexibility, and rebound resilience. The translucent design allows easy observation of fluid flow.
Available in ID 1~20mm with wall thickness 1.5~4mm, suitable for peristaltic pumps, condenser connections, gas transfer, and food-grade applications. Non-toxic and odorless, meeting food-grade and medical-grade requirements.
🔬 Product Advantages:
Wide Temperature Range — -60~250°C for various environments
Translucent Design — Easy observation of fluid flow
Good Flexibility — Excellent bending performance
Non-Toxic — Food-grade and medical-grade compliant
Multiple Sizes — ID 1~20mm full coverage
II. Key Performance Parameters
- Material: Silicone (VMQ)
- ID Range: 1~20mm
- Wall Thickness: 1.5~4mm
- Temperature Range: -60°C ~ 250°C
- Hardness: 60~70 Shore A
- Features: Translucent, non-toxic, flexible
III. Material & Manufacturing
Manufactured from high-quality silicone rubber (VMQ) via extrusion molding. Features uniform wall thickness, smooth surface, and no bubbles or impurities. Translucent design allows easy observation of fluid flow.
Silicone rubber offers excellent weather resistance and chemical stability, maintaining good elasticity and flexibility across a wide temperature range.
