Specifications

Complete specifications for PTFE tweezers. Items marked Customizable available upon request.

I. Full PTFE Tweezers

Length (mm)	Width (mm)	Thickness (mm)	Opening (mm)	Tip Type
100	30	10	11	Straight / Curved
150	40	10	15	Straight / Curved
200	43	10	20	Straight / Curved
300	46	15	18	Straight / Curved

II. Stainless Handle + PTFE Tip Tweezers

Tip Type	Tip Size	Features
Pointed	1mm tip	Precision handling, fine gripping
Pointed	3mm tip	Precision handling, medium accuracy
Curved	1mm tip	Tight space operations
Flat	8mm width	Handling larger flat objects
Wide	20mm width	Handling large-area objects

Custom lengths and tip shapes available upon request.

📌 Customization Options:
• Material: Full PTFE / Stainless handle + PTFE tip / Titanium handle + PTFE tip
• Tip Types: Straight / Curved / Pointed (1/2/3mm) / Flat (8/20mm) / Custom
• Custom lengths and tip shapes available upon request — consult our technical team

Product Description

I. Overview

PTFE tweezers are precision-manufactured from high-purity PTFE resin, available in full PTFE and stainless handle + PTFE tip versions. Full PTFE tweezers are designed for highly corrosive environments ensuring zero metal ion contamination. Stainless handle + PTFE tip tweezers offer superior mechanical strength and handling comfort for routine laboratory use.

PTFE's extremely low surface tension (18.5 mN/m) provides non-stick properties — minimal sample residue and easy cleaning. Precision-ground tips provide smooth, flat gripping surfaces that will not damage samples.

Available in 100mm, 150mm, 200mm, and 300mm lengths with straight, curved, pointed, and flat tip options. Widely used in pharmaceutical, semiconductor, environmental testing, and materials science laboratories for sample handling, transfer, and positioning.

II. Core Performance Parameters

Material: High-purity PTFE (full PTFE) / Stainless handle + PTFE tip
Operating Temperature: -196℃ ~ 260℃
Chemical Resistance: Resistant to HF, aqua regia, concentrated H₂SO₄, HNO₃, strong alkalis, organic solvents
Surface: Non-stick, low friction, easy to clean
Tip Types: Straight / Curved / Pointed / Flat
Lengths: 100mm / 150mm / 200mm / 300mm

III. Material & Workmanship

Full PTFE tweezers are precision-molded or machined from imported high-purity PTFE resin — smooth surfaces, no burrs, flat gripping faces. Stainless handle + PTFE tip tweezers combine stainless steel handles with precision-attached PTFE tips for excellent mechanical strength and chemical inertness.

Tips are precision-ground to provide smooth, flat gripping surfaces that will not scratch or contaminate samples. Handle tension is optimally balanced for comfortable extended use.

All products are manufactured and packaged in cleanroom environments to ensure particle-free, contaminant-free surfaces.

Applications

Typical Applications

Sample Handling & Transfer

Handling and transferring samples in corrosive environments without direct contact

Precision Operations

Precise handling and positioning of electronic components, optical devices, wafers

Cleanroom Operations

Sample handling in semiconductor, pharmaceutical, and other cleanroom environments

Slide/Coverslip Operations

Handling and placing microscope samples

Corrosive Chemical Operations

Handling containers or samples in strong acid/base environments

Industries

Pharmaceutical Drug sample handling, cleanroom operations
Semiconductor Wafer handling, photoresist processing
Chemistry Labs Corrosive sample operations
Environmental Testing Sample prep and transfer
Research General laboratory operations

Chemical	PTFE Compatibility	Recommended Temperature	Notes
Hydrofluoric Acid (HF)	✅ Fully Compatible	≤ 250℃	PTFE is the only reliable material
Aqua Regia	✅ Fully Compatible	≤ 200℃	Avoid extreme conditions
Conc. H₂SO₄ (98%)	✅ Fully Compatible	≤ 250℃	Handle with care when heating
Conc. HNO₃ (65%)	✅ Fully Compatible	≤ 250℃	Store away from light
NaOH (50%)	✅ Fully Compatible	≤ 200℃	Safe handling required for concentrated alkalis
Organic Solvents	✅ Fully Compatible	≤ Solvent BP	Ensure ventilation and fire safety

Selection Guide

I. By Application

Application	Recommended Version	Recommended Length	Recommended Tip
Highly corrosive environments	Full PTFE	150-200mm	Straight / Curved
Precision sample handling	SS Handle + PTFE Tip	100-150mm	Pointed 1mm
General lab operations	SS Handle + PTFE Tip	150-200mm	Straight / Curved
Semiconductor/cleanroom	Full PTFE	150-200mm	Straight
Tight space operations	SS Handle + PTFE Tip	200-300mm	Curved
Larger objects	SS Handle + PTFE Tip	200-300mm	Flat / Wide

II. Tip Type Selection

Straight: Most versatile — suitable for the majority of handling operations
Curved: Suitable for tight spaces and angled operations
Pointed (1mm/3mm): For precision handling — micro-samples, electronic components, wafers
Flat (8mm): For handling larger flat objects — slides, cover glasses
Wide (20mm): For handling large-area objects — films, paper

💡 Selection Tip: For highly corrosive environments (HF, aqua regia operations), always choose Full PTFE tweezers — no metal parts exposed.
For precision handling (micro-samples, electronic components), choose Stainless handle + PTFE tip tweezers, pointed 1mm.
For general laboratory use, Stainless handle + PTFE tip, straight 150mm is the most versatile choice.
Length selection: Spacious workspace → short tweezers (100-150mm); deep vessels or tight spaces → long tweezers (200-300mm).

Operation & Maintenance

User Guide

Standard operating guidelines for PTFE tweezers. Proper use and maintenance ensure handling precision and product longevity.

I. Pre-use Preparation

Inspect the tips — ensure gripping surfaces are smooth and undamaged
Check tension — ensure gripping force is appropriate
Clean with ultrapure water or appropriate solvent to remove surface particles
For cleanroom applications, open and use in a clean environment

II. Handling Operation

Hold the handle with thumb and forefinger to control gripping force
Position the tips over the target sample — grip gently
Apply moderate force — avoid excessive pressure that might damage the sample or tweezers
Maintain steady control during transfer to prevent sample drop

III. Cleaning & Maintenance

Clean with ultrapure water or appropriate solvent after use — PTFE's non-stick surface makes cleaning easy
Stubborn residues may be soaked in dilute nitric acid
Air dry or wipe dry
Store in a clean, dry location — avoid tip deformation from pressure

IV. Important Notes

Avoid tip impact with hard objects — prevent deformation or damage
Avoid exceeding rated temperature during prolonged use
Never use hard brushes or abrasives for cleaning
Full PTFE tweezers are relatively soft — use care when handling heavy objects
For stainless handle + PTFE tip tweezers, avoid impact between the PTFE tip and hard surfaces

💡 From a Seasoned Lab Technician: "Gentle grip, steady hand" — PTFE is relatively soft, avoid excessive force during gripping to prevent tip damage or sample surface marks.
For micro-samples, use pointed 1mm tweezers — a light touch is sufficient (PTFE's low surface tension helps).
After use in corrosive environments, clean the tweezers immediately to prevent chemical residue from attacking the surface.
When using curved tweezers, leverage the angled tip to reach samples in tight spaces.

Care & Notes

Show care & notes

⚠️ Safety & Compliance Checklist

Chemical Safety

Operations in corrosive environments must be performed in a fume hood

PPE

Safety goggles, lab coat, acid/alkali resistant gloves required

Cleanroom

Cleanroom tweezers should be opened and used in clean environments

Compliance

All operations should follow laboratory safety guidelines
